| 加工定制：否 | 品牌：KCC | 型号：KHS系列 |
| 材质：硅橡胶 | 阻燃性：℃ | 耐温：125（℃） ℃ |
| 耐压：见说明（KV） KV | 颜色：见说明 | 产品认证：见说明 |
-55℃~125℃
环保性能符合Sony与欧盟RoHS等环保批准
型号
Item No.
| 规格
| 收缩前尺寸(mm)
| 收缩后尺寸(mm)
| 标准包装
| 使用范围
(mm)
| ||||
内径
| 壁厚
| 内径
| 壁厚
| 米/盘
| 盘/箱
| 包装箱规格(cm)
| |||
KHS-3/64
| Φ0.8
| 1.1±0.2
| 0.15±0.05
| ≤0.50
| 0.22±0.10
| 200
| 23
| 31×31×44.5
| 0.6~0.8
|
KHS-1/16
| Φ1.0
| 1.5±0.2
| 0.15±0.05
| ≤0.65
| 0.28±0.10
| 200
| 16
| 31×31×44.5
| 0.75~0.9
|
KHS-3/32
| Φ2.0
| 2.5±0.2
| 0.18±0.05
| ≤1.00
| 0.35±0.10
| 200
| 15
| 46×46×44.5
| 1.1~1.8
|
KHS-1/8
| Φ3.0
| 3.5±0.2
| 0.18±0.05
| ≤1.50
| 0.40±0.10
| 200
| 11
| 46×46×44.5
| 1.6~2.7
|
KHS-3/16
| Φ4.5
| 5.0±0.2
| 0.25±0.05
| ≤2.30
| 0.50±0.10
| 100
| 10
| 46×46×44.5
| 2.4~4.0
|
KHS-1/4
| Φ6.0
| 6.5±0.2
| 0.28±0.05
| ≤3.0
| 0.55±0.10
| 100
| 7
| 46×46×44.5
| 3.1~5.4
|
KHS-3/8
| Φ9.0
| 9.5±0.3
| 0.30±0.08
| ≤4.5
| 0.6±0.10
| 100
| 12
| 46×46×31
| 4.7~8.0
|
KHS-1/2
| Φ12
| 12.5±0.3
| 0.30±0.08
| ≤6.0
| 0.6±0.10
| 100
| 10
| 46×46×31
| 6.2~11
|
KHS-3/4
| Φ18
| 19.0±0.5
| 0.40±0.15
| ≤9.0
| 0.80±0.15
| 100
| 7
| 46×46×29.5
| 9.3~17
|
KHS-1
| Φ25
| 26.0±0.5
| 0.50±0.15
| ≤12.5
| 0.90±0.15
| 50
| 6
| 46×46×31
| 12.9~24
|
KHS-1-1/4
| Φ28
| 29.0±0.5
| 0.50±0.15
| ≤14.0
| 0.90±0.15
| 50
| 5
| 46×46×29.5
| 14.4~27
|
KHS-1-1/2
| Φ40
| 41.5±1.0
| 0.55±0.15
| ≤20.0
| 1.00±0.15
| 50
| 4
| 46×46×31
| 21~39
|
KHS-2
| Φ50
| ≥50
| 0.55±0.15
| ≤25.0
| 1.00±0.15
| 25
| 5
| 46×46×44.5
| 26~49
|
KHS-3
| Φ80
| ≥80
| 0.65±0.15
| ≤41.0
| 1.46±0.20
| 25
| 3
| 31×31×42
| 45~75
|
KHS-4
| Φ100
| ≥100
| 0.65±0.20
| ≤51.0
| 1.46±0.20
| 25
| 2
| 31×31×34.5
| 55~95
|
KHS-5
| Φ120
| ≥120
| 0.65±0.20
| ≤61.0
| 1.56±0.20
| 15
| 2
| 31×31×40.5
| 65~115
|
型号
Item No.
| 收缩前尺寸(mm)
| 收缩后尺寸(mm)
| 标准包装
| 使用范围
(mm)
| ||||
内径
| 壁厚
| 内径
| 壁厚
| 米/盘
| 盘/箱
| 包装箱规格(cm)
| ||
KHS-0.6
| 0.9±0.2
| 0.15±0.05
| ≤0.40
| 0.22±0.10
| 200
| 23
| 31×31×44.5
| 0.5~0.7
|
KHS-0.8
| 1.1±0.2
| 0.15±0.05
| ≤0.50
| 0.22±0.10
| 200
| 23
| 31×31×44.5
| 0.6~0.8
|
KHS-1.0
| 1.5±0.2
| 0.15±0.05
| ≤0.65
| 0.28±0.10
| 200
| 16
| 31×31×44.5
| 0.75~0.9
|
KHS-1.5
| 2.0±0.2
| 0.18±0.05
| ≤0.85
| 0.32±0.10
| 200
| 12
| 31×31×44.5
| 0.95~1.4
|
KHS-2.0
| 2.5±0.2
| 0.18±0.05
| ≤1.00
| 0.35±0.10
| 200
| 15
| 46×46×44.5
| 1.1~1.8
|
KHS-2.5
| 3.0±0.2
| 0.18±0.05
| ≤1.30
| 0.38±0.10
| 200
| 13
| 46×46×44.5
| 1.4~2.3
|
KHS-3.0
| 3.5±0.2
| 0.18±0.05
| ≤1.50
| 0.40±0.10
| 200
| 11
| 46×46×44.5
| 1.6~2.7
|
KHS-3.5
| 4.0±0.2
| 0.22±0.05
| ≤1.80
| 0.42±0.10
| 200
| 9
| 46×46×44.5
| 1.9~3.2
|
KHS-4.0
| 4.5±0.2
| 0.25±0.05
| ≤2.00
| 0.45±0.10
| 200
| 7
| 46×46×44.5
| 2.1~3.6
|
KHS-4.5
| 5.0±0.2
| 0.25±0.05
| ≤2.30
| 0.50±0.10
| 100
| 10
| 46×46×44.5
| 2.4~4.0
|
KHS-5.0
| 5.5±0.2
| 0.25±0.05
| ≤2.5
| 0.55±0.10
| 100
| 9
| 46×46×44.5
| 2.6~4.5
|
KHS-5.5
| 6.0±0.2
| 0.25±0.05
| ≤2.75
| 0.55±0.10
| 100
| 8
| 46×46×44.5
| 2.85~5.0
|
KHS-6.0
| 6.5±0.2
| 0.28±0.05
| ≤3.0
| 0.55±0.10
| 100
| 7
| 46×46×44.5
| 3.1~5.4
|
KHS-7.0
| 7.5±0.3
| 0.28±0.05
| ≤3.5
| 0.55±0.10
| 100
| 14
| 46×46×31
| 3.7~6.3
|
KHS-8.0
| 8.5±0.3
| 0.28±0.05
| ≤4.0
| 0.6±0.10
| 100
| 13
| 46×46×31
| 4.2~7.2
|
KHS-9.0
| 9.5±0.3
| 0.30±0.08
| ≤4.5
| 0.6±0.10
| 100
| 12
| 46×46×31
| 4.7~8.0
|
KHS-10
| 10.5±0.3
| 0.30±0.08
| ≤5.0
| 0.6±0.10
| 100
| 11
| 46×46×31
| 5.2~9.0
|
KHS-11
| 11.5±0.3
| 0.30±0.08
| ≤5.5
| 0.6±0.10
| 100
| 11
| 46×46×31
| 5.7~10
|
KHS-12
| 12.5±0.3
| 0.30±0.08
| ≤6.0
| 0.6±0.10
| 100
| 10
| 46×46×31
| 6.2~11
|
KHS-13
| 13.5±0.3
| 0.35±0.10
| ≤6.5
| 0.65±0.10
| 100
| 9
| 46×46×29.5
| 6.7~12
|
KHS-14
| 14.5±0.3
| 0.35±0.10
| ≤7.0
| 0.65±0.10
| 100
| 9
| 46×46×31
| 7.3~13
|
KHS-15
| 15.5±0.4
| 0.40±0.12
| ≤7.5
| 0.70±0.10
| 100
| 8
| 46×46×29.5
| 7.8~14
|
KHS-16
| 16.5±0.4
| 0.40±0.12
| ≤8.0
| 0.70±0.10
| 100
| 8
| 46×46×31
| 8.3~15
|
KHS-17
| 17.5±0.4
| 0.40±0.12
| ≤8.5
| 0.70±0.10
| 100
| 7
| 46×46×29.5
| 8.8~16
|
KHS-18
| 19.0±0.5
| 0.40±0.15
| ≤9.0
| 0.80±0.15
| 100
| 7
| 46×46×29.5
| 9.3~17
|
KHS-20
| 21.0±0.5
| 0.40±0.15
| ≤10.0
| 0.80±0.15
| 100
| 6
| 46×46×29.5
| 10.4~19
|
KHS-22
| 23.0±0.5
| 0.40±0.15
| ≤11.0
| 0.80±0.15
| 100
| 6
| 46×46×31
| 11.4~21
|
KHS-25
| 26.0±0.5
| 0.50±0.15
| ≤12.5
| 0.90±0.15
| 50
| 6
| 46×46×31
| 12.9~24
|
KHS-28
| 29.0±0.5
| 0.50±0.15
| ≤14.0
| 0.90±0.15
| 50
| 5
| 46×46×29.5
| 14.4~27
|
KHS-30
| 31.5±1.0
| 0.50±0.15
| ≤15.0
| 0.95±0.15
| 50
| 5
| 46×46×31
| 16~29
|
KHS-35
| 36.5±1.0
| 0.50±0.15
| ≤17.5
| 1.00±0.15
| 50
| 4
| 46×46×29.5
| 18~34
|
KHS-40
| 41.5±1.0
| 0.55±0.15
| ≤20.0
| 1.00±0.15
| 50
| 4
| 46×46×31
| 21~39
|
KHS-45
| 46.5±1.0
| 0.55±0.15
| ≤22.5
| 1.00±0.15
| 25
| 5
| 31×31×40.5
| 23.5~44
|
KHS-50
| ≥50
| 0.55±0.15
| ≤25.0
| 1.00±0.15
| 25
| 5
| 31×31×44.5
| 26~49
|
KHS-60
| ≥60
| 0.60±0.15
| ≤31.0
| 1.30±0.20
| 25
| 4
| 31×31×42
| 35~55
|
KHS-70
| ≥70
| 0.65±0.15
| ≤36.0
| 1.30±0.20
| 25
| 3
| 31×31×37
| 40~65
|
KHS-80
| ≥80
| 0.65±0.15
| ≤41.0
| 1.46±0.20
| 25
| 3
| 31×31×42
| 45~75
|
KHS-90
| ≥90
| 0.65±0.15
| ≤46.0
| 1.46±0.20
| 25
| 2
| 31×31×32
| 50~85
|
KHS-100
| ≥100
| 0.65±0.20
| ≤51.0
| 1.46±0.20
| 25
| 2
| 31×31×34.5
| 55~95
|
KHS-120
| ≥120
| 0.65±0.20
| ≤61.0
| 1.56±0.20
| 15
| 2
| 31×31×40.5
| 65~115
|
KHS-150
| ≥150
| 0.65±0.20
| ≤76.0
| 1.56±0.20
| 15
| 2
| 31×31×49.5
| 80~145
|
KHS-180
| ≥180
| 0.65±0.30
| ≥91.0
| 1.56±0.20
| 15
| 1
| 31×31×31
| 95~175
|
